Kevollaser Laser Rotary Platform Stainless Steel Anti-corrosion Compatible with CO₂ and Fiber Lasers
Brief Description
- Product: Dual-Station High-Precision Laser Rotary Platform
- Positioning Accuracy: ±0.005°
- Rotation Speed: Max 2000 rpm
- Station Modes: 18/36 Switchable
- Switching Time: ≤28 Seconds
- Linear Travel: 200mm / 300mm Optional
- Clamping Type: Pneumatic 3-Jaw Chuck / ER Collet
- Control System: Automation1 iSMC
- Processing Capacity: Up to 1150 Pieces/Hour
Kevollaser Laser Rotary Platform Stainless Steel Anti-corrosion Compatible with CO₂ and Fiber Lasers
Product Introduction
The Laser Rotary Platform is a high-precision, multi-functional laser processing system engineered for 360° continuous engraving, marking, and cutting of cylindrical, tapered, and irregular workpieces. As a top-tier laser rotary platform, it integrates dual-station switching (18/36 stations) and direct-drive servo technology, delivering exceptional positioning accuracy of ±0.005° and repeatability of ±15 μrad for consistent, high-quality results. With a maximum rotation speed of 2000 rpm and dual laser head symmetric layout, it enables simultaneous two-sided marking, boosting efficiency by 80-95% compared to single-head systems.
Compatible with CO₂ and fiber lasers, this laser rotary platform supports a wide range of materials including metals, plastics, glass, ceramics, and composites, handling workpieces of varying sizes via quick station switching (≤28 seconds). Equipped with an advanced Automation1 control system and PSO (Position Synchronized Output) technology, it ensures laser pulse frequency synchronizes with rotation speed for distortion-free marking. Whether used for precision engraving of electronic components, UDI coding on medical devices, or防伪 marking on automotive parts, this laser rotary platform combines versatility, speed, and accuracy to meet the demands of high-volume, high-precision manufacturing and creative engraving applications.
Product Features
- Dual-station flexibility: Switch between 18-station (20°/station) and 36-station (10°/station) modes for small/large workpiece compatibility
- Ultra-high precision: ±0.005° positioning accuracy and ±0.5μm linear repeatability, supported by five-point calibration system (±0.01mm calibration precision)
- High-speed operation: Max rotation speed of 2000 rpm and 12°/sec rotation rate (36-station mode) for high-throughput processing (up to 1150 pieces/hour)
- Double-sided synchronous marking: Symmetric 180° laser head layout enables simultaneous two-sided processing, cutting cycle time in half
- Intelligent control system: Automation1 iSMC controller with HyperWire® fiber bus for millisecond-level synchronization and dynamic error compensation
- Tool-free quick switching: Pneumatic unlocking and servo-driven station change (≤28 seconds) with automatic parameter adaptation
- Multi-material compatibility: Works with metals, plastics, glass, ceramics, and composites, supporting both dry and wet cutting modes
- Comprehensive protection: Real-time monitoring of temperature, vibration, and laser power with automatic drift compensation and fault alerts
- Easy integration: MES/ERP integration capability via Ethernet, supporting BMP/JPG/DXF/PLT/AI file formats and automatic serial number/QR code generation
Product Specification Table
<<
| Specification Item</ | Details</ |
|---|---|
| Product Type | Dual-Station Laser Rotary Platform |
| Rotation Range | ±360° Continuous Rotation |
| Positioning Accuracy | ±0.005° |
| Rotational Repeatability | ±15 μrad (±3 arcseconds) |
| Max Rotation Speed | 2000 rpm |
| Station Configuration | 18-station (20°/station) & 36-station (10°/station) switchable |
| Station Switching Time | ≤28 Seconds |
| Linear Axis Travel | 200mm / 300mm Optional |
| Linear Positioning Accuracy | ±1 μm (Calibrated); ±5 μm (Uncalibrated) |
| Clamping System | Pneumatic 3-Jaw Chuck / ER Collet (0-20.3mm Diameter Range) |
| Compatible Lasers | CO₂ Laser, Fiber Laser |
| Processing Efficiency | Up to 1150 Pieces/Hour (18-station Mode) |
| Control System | Automation1 iSMC with HyperWire® Fiber Bus |
| Supported File Formats | BMP, JPG, DXF, PLT, AI |
| Operating Temperature | 0℃~40℃ |
| Power Supply | AC 220V±10% / 380V±10%, 50/60Hz |
| Protection Rating | IP54 |
Brief Description
- Product: Dual-Station High-Precision Laser Rotary Platform
- Positioning Accuracy: ±0.005°
- Rotation Speed: Max 2000 rpm
- Station Modes: 18/36 Switchable
- Switching Time: ≤28 Seconds
- Linear Travel: 200mm / 300mm Optional
- Clamping Type: Pneumatic 3-Jaw Chuck / ER Collet
- Control System: Automation1 iSMC
- Processing Capacity: Up to 1150 Pieces/Hour
Application Areas
This versatile laser rotary platform is ideal for high-precision processing across multiple industries, including:
- Electronics Industry: PCB boards, chip packaging, connectors, and electronic component marking (serial numbers, QR codes)
- Medical Devices: UDI coding on bone screws, surgical instruments, and implantable medical parts
- Automotive Manufacturing: Marking on pistons, shafts, electronic control units (ECUs), and auto accessories
- Precision Engineering: Engraving on hardware tools, measuring instruments, and mechanical components
- Consumer Goods: Custom engraving on glassware, stainless steel tumblers, ceramic products, and plastic accessories
- Jewelry & Watchmaking: Intricate marking on metal jewelry, watch cases, and watch bands
- Aerospace Components: Lightweight material marking and identification for aircraft parts
- Packaging Industry: Anti-counterfeiting marking on product packaging and containers
